Marine Pump Solutions

MPS-550

Marine Air Conditioner Pump MPS-550 120VAC, 650 GPH

SPECIFICATIONS

  • Dimensions: 5.0" long x 3.8" wide x 5.25" high
  • Voltage: 120 V ac (220 V ac pumps available please contact)
  • Power Cord Length: 10 feet
  • Maximum Flow: 650 gallons per hour @ 1' rise
  • Inlet: 3/4" Female Pipe Thread
  • Outlet: 3/4" M ale Pipe Thread

The MPS-550 Marine Air Conditioner Pump is a magnetically driven centrifugal water pump with a ceramic shaft designed for marine air conditioners used in fresh or saltwater. It has no seals to wear and contains no oil. The only serviceable item is the impeller which can easily be cleaned or replaced when needed.  (Mounting screws not included)

Note: The “New” MPS 550 will give a more consistent flow through the mid-range of Pump heights, changing the input and output of the pump from ½” to ¾” is just one of the changes made.

PUMP FEATURES

  • The Pump can be used Submerged or Mounted Inline.
    • Inline - connections are made directly to the pump inlet and outlet port (AC applications)
    •  Submerged - for underwater applications
  • All Electrical Components are Encapsulated in Epoxy
    • No Seals to Wear
    • No Oil to Leak
  • Type 316 Marine Grade Stainless Steel Hardware
  • Uses Half The Power of Regular Driven Pumps
  • Reliable 24/7 performance
  • Includes: MPS-550 Pump with 10' Power Cord, (2) 3/4" to 5/8" adapters,(1) Mounting Bracket, (2) Nylon Straps
  • UL / CUL Listed
  • Best in Class 5 Year Manufacturer Limited Warranty
  • Replacement Parts are Available
  • This product is supplied with mounting & Fittings

Flow rate (GPH)

 Name MPS-550
Flow at 1' 650
Flow at 2' 650
Flow at 3' 625
Flow at 4' 600
Flow at 5' 590
Flow at 6' 575
Flow at 7' 550
Flow at 8' 525
Flow at 9' 500
Flow at 10' 475
Flow at 15' -
Shut-Off (Feet) 10' 6"
